Inheritance diagram for gem::MapViewRouteCollection:

[legend]

Collaboration diagram for gem::MapViewRouteCollection:

[legend]

Public Member Functions
const RouteRenderSettings *	getRenderSettings (const Route &route) const noexcept
	Get the route custom render settings(read-only).
MapViewRouteCollection &	setRenderSettings (const Route &route, const RouteRenderSettings &settings) noexcept
	Set the route custom render settings.
const StringRef	getLabel (const Route &route) const noexcept
	Get route label text.
MapViewRouteCollection &	setLabel (const Route &route, const String &text) noexcept
	Set route bubble text.
const ImageListRef	getImages (const Route &route) const noexcept
	Get route bubble image list.
MapViewRouteCollection &	setImages (const Route &route, const ImageList &images) noexcept
	Set route bubble images list, see setLabel for details.
MapViewRoute	getMapViewRoute (int idx) const noexcept
	Get map view route in collection by index.
MapViewRoute	getMapViewRoute (const Route &route) const noexcept
	Get map view route in collection by route.
RouteCollection &	add (const Route &route, bool bMainRoute, const String &label=String(), const ImageList &images=ImageList()) noexcept
	Add or update a route in the collection.
MapViewRouteCollection &	add (const Route &route, const RouteRenderSettings &settings, const String &label=String(), const ImageList &images=ImageList()) noexcept
	Add or update a route in the collection with the given render settings.
MapViewRouteCollection &	add (const MapViewRoute &route) noexcept
	Add or update a map view route in the collection.
MapViewRouteCollection &	hideLabel (const Route &route)
	Hide route label.
template<typename TCollector>
bool	iterateMapViewRoutes (TCollector collector) const
	Iterate all map view routes in the collection.
int	size () const noexcept
	Get number of routes in this collection.
const RouteRef	getRoute (int index) const noexcept
	Get route specified by index.
int	indexOf (const Route &route) const noexcept
	Get index of the specified route - return < 0 for error.
bool	isMainRoute (const Route &route) const noexcept
	Check if the route is the main route in the collection.
const RouteRef	getMainRoute () const noexcept
	Get the current main route.
RouteCollection &	setMainRoute (const Route &route) noexcept
	Set the route as main route in the collection.
RouteCollection &	add (const Route &route, bool bMainRoute) noexcept
	Add a route in the collection.
RouteCollection &	remove (const Route &route) noexcept
	Remove the route specified by Route.
bool	contains (const Route &route) const noexcept
	Check if a route object is in collection.
void	clear () noexcept
	Remove all routes.
template<typename TCollector>
bool	iterateRoutes (TCollector collector) const
	Iterate all routes in the collection.

Detailed Description

MapViewRouteCollection object.

Implements a routes collection for MapView preferences

Member Function Documentation

◆ add() [1/4]

MapViewRouteCollection & gem::MapViewRouteCollection::add ( const MapViewRoute & route )

inlinenoexcept

Add or update a map view route in the collection.

If the route already exists in the collection, it will be updated with the new settings

Parameters

[in] route The map view route to be added / updated

Returns: MapViewRouteCollection object

◆ add() [2/4]

RouteCollection & gem::MapViewRouteCollection::add	(	const Route &	route,
		bool	bMainRoute,
		const String &	label = String(),
		const ImageList &	images = ImageList() )

inlinenoexcept

Add or update a route in the collection.

If the route already exists in the collection, it will be updated with the new settings

Parameters

[in]	route	The route to be added / updated
[in]	bMainRoute	True if the route is the main route, false if it is an alternative route
[in]	label	Route label string
[in]	images	Route label images

Returns: RouteCollection object

◆ add() [3/4]

MapViewRouteCollection & gem::MapViewRouteCollection::add	(	const Route &	route,
		const RouteRenderSettings &	settings,
		const String &	label = String(),
		const ImageList &	images = ImageList() )

inlinenoexcept

Add or update a route in the collection with the given render settings.

If the route already exists in the collection, it will be updated with the new settings

Parameters

[in]	route	The route to be added / updated
[in]	settings	The route render settings
[in]	label	Route label string
[in]	images	Route label images

Returns: MapViewRouteCollection object

◆ add() [4/4]

RouteCollection & gem::RouteCollection::add	(	const Route &	route,
		bool	bMainRoute )

inlinenoexceptinherited

Add a route in the collection.

Parameters

[in]	route	The route to be added.
[in]	bMainRoute	True if the route is the main route, false if alternative route

Returns: RouteCollection object

◆ contains()

bool gem::RouteCollection::contains ( const Route & route ) const

inlinenoexceptinherited

Check if a route object is in collection.

Parameters

[in] route The route to be checked

Returns: True if the route is in the collection

◆ getImages()

const ImageListRef gem::MapViewRouteCollection::getImages ( const Route & route ) const

inlinenoexcept

Get route bubble image list.

Parameters

[in] route The route for which the images are requested

Returns: The images list

◆ getLabel()

const StringRef gem::MapViewRouteCollection::getLabel ( const Route & route ) const

inlinenoexcept

Get route label text.

Parameters

[in] route The route for which the label wants to be retrieved

Returns: The actual label

◆ getMainRoute()

const RouteRef gem::RouteCollection::getMainRoute ( ) const

inlinenoexceptinherited

Get the current main route.

Returns: The main route in the collection

◆ getMapViewRoute() [1/2]

MapViewRoute gem::MapViewRouteCollection::getMapViewRoute ( const Route & route ) const

inlinenoexcept

Get map view route in collection by route.

Parameters

[in] route The route attached to the map view route

Returns: The MapViewRoute object

◆ getMapViewRoute() [2/2]

MapViewRoute gem::MapViewRouteCollection::getMapViewRoute ( int idx ) const

inlinenoexcept

Get map view route in collection by index.

Parameters

[in] idx The map view route index in collection

Returns: The MapViewRoute object

◆ getRenderSettings()

const RouteRenderSettings * gem::MapViewRouteCollection::getRenderSettings ( const Route & route ) const

inlinenoexcept

Get the route custom render settings(read-only).

Parameters

[in] route The route for which the render settings are requested

Returns: The route render settings

◆ getRoute()

const RouteRef gem::RouteCollection::getRoute ( int index ) const

inlinenoexceptinherited

Get route specified by index.

Parameters

[in] index The index of the route in the collection

Returns: The route object

◆ hideLabel()

MapViewRouteCollection & gem::MapViewRouteCollection::hideLabel ( const Route & route )

inline

Hide route label.

Parameters

[in] route The route for which the label should be hidden

Returns: MapViewRouteCollection object

◆ indexOf()

int gem::RouteCollection::indexOf ( const Route & route ) const

inlinenoexceptinherited

Get index of the specified route - return < 0 for error.

Parameters

[in] route The route to be found

Returns: The index of the route in the collection

◆ isMainRoute()

bool gem::RouteCollection::isMainRoute ( const Route & route ) const

inlinenoexceptinherited

Check if the route is the main route in the collection.

Parameters

[in] route The route to be checked

Returns: True if the route is the main route in the collection

◆ iterateMapViewRoutes()

template<typename TCollector>

bool gem::MapViewRouteCollection::iterateMapViewRoutes ( TCollector collector ) const

inline

Iterate all map view routes in the collection.

Collector should return true if iteration should continue and false if iteration should stop

Parameters

[in] collector The collector function

Returns: true if all routes were iterated, false if iteration was stopped

◆ iterateRoutes()

template<typename TCollector>

bool gem::RouteCollection::iterateRoutes ( TCollector collector ) const

inlineinherited

Iterate all routes in the collection.

Collector should return true if iteration should continue and false if iteration should stop

Parameters

[in] collector The collector function

Returns: true if all routes were iterated, false if iteration was stopped

◆ remove()

RouteCollection & gem::RouteCollection::remove ( const Route & route )

inlinenoexceptinherited

Remove the route specified by Route.

Parameters

[in] route route in the collection

Returns: RouteCollection object

◆ setImages()

MapViewRouteCollection & gem::MapViewRouteCollection::setImages	(	const Route &	route,
		const ImageList &	images )

inlinenoexcept

Set route bubble images list, see setLabel for details.

Parameters

[in]	route	The route for which the images are set
[in]	images	The images list

Returns: MapViewRouteCollection object

◆ setLabel()

MapViewRouteCollection & gem::MapViewRouteCollection::setLabel	(	const Route &	route,
		const String &	text )

inlinenoexcept

Set route bubble text.

Parameters

[in]	route	The route for which the label wants to be set
[in]	text	The actual label

The route label supports custom icon placement inside the text by using the icon place-mark %icon index%%, e.g. "My header text %%0%%\n%%1%% my footer"

The %icon index%% must be a valid integer in images list container, i.e. 0 <= icon index < images.size()

Returns: MapViewRouteCollection object

◆ setMainRoute()

RouteCollection & gem::RouteCollection::setMainRoute ( const Route & route )

inlinenoexceptinherited

Set the route as main route in the collection.

Parameters

[in] route The route to be set as main route

Returns: RouteCollection object

◆ setRenderSettings()

MapViewRouteCollection & gem::MapViewRouteCollection::setRenderSettings	(	const Route &	route,
		const RouteRenderSettings &	settings )

inlinenoexcept

Set the route custom render settings.

Parameters

[in]	route	The route for which the render settings are set
[in]	settings	The route render settings

Returns: MapViewRouteCollection object

◆ size()

int gem::RouteCollection::size ( ) const

inlinenoexceptinherited

Get number of routes in this collection.

Returns: The number of routes in the collection.
