MapCustomization object. More...

Inheritance diagram for gem::MapViewExtensions:

[legend]

Collaboration diagram for gem::MapViewExtensions:

[legend]

Public Member Functions
void	setMinimumAllowedZoomLevel (int zoomLevel) noexcept
	Set the minimum allowed zoom level.
int	getMinimumAllowedZoomLevel () const noexcept
	Get the minimum allowed zoom level.
MapViewExtensions &	setMaximumAllowedZoomLevel (int zoomLevel) noexcept
	Set the maximum allowed zoom level.
int	getMaximumAllowedZoomLevel () const noexcept
	Get the maximum allowed zoom level.
int	getHighlightGroupItemIndex (int idx, int highlightId=0) const noexcept
	Get group highlighted item index for the given highlighted item index ( in original list ).
MapViewExtensions &	setNavigationRouteLowRateUpdate (bool enable) noexcept
	set navigation route low rate update
bool	getNavigationRouteLowRateUpdate () const noexcept
	get navigation route low rate update
MapViewExtensions &	setNavigationRouteUpdateRate (ENavigationRouteUpdateRate rate) noexcept
	set navigation route update rate
ENavigationRouteUpdateRate	getNavigationRouteUpdateRate () const noexcept
	get navigation route update rate
MapViewExtensions &	setLowEndCPUOptimizations (bool enable) noexcept
	Enable optimizations for low end CPU.
bool	getLowEndCPUOptimizations () const noexcept
	Get low end CPU optimizations flag.
int	getMarkersFromRouteGeometry (std::function< void(MarkerCollection, ERouteGeometryMarkerType)> collector, const DataBuffer &data) const noexcept
	Generate markers collection from route packed geometry.
std::pair< MarkerCollection, AbstractGeometryImage >	getMarkersFromRouteInstructionGeometry (const DataBuffer &data) const noexcept
	Generate marker collection from route instruction packed geometry.
std::pair< RouteTrafficEventList, int >	getMarkersFromRouteTrafficGeometry (std::function< void(MarkerCollection, ETrafficEventSeverity)> collector, const DataBuffer &data) const noexcept
	Generate markers collection from route traffic packed geometry.
int	createTexture (IBitmap &bmp) const noexcept
	Create texture from the given bitmap.
int	deleteTexture (int textureId) const noexcept
	Delete a texture previously created with createTexture.
int	renderTexture (int textureId, const Rect &place) const noexcept
	Render bitmap in the map view.
int	startTrackPositions (int updatePositionMs, const MarkerCollectionRenderSettings &settings, sense::DataSourcePtr ds={}) noexcept
	Start the sense data source improved position tracking on map by rendering a marker polyline between relevant map links points.
std::pair< CoordinatesList, int >	getTrackedPositions () const noexcept
	Get the current tracked positions as a coordinates list.
bool	isTrackedPositions () const noexcept
	Check if tracked position is started in the map view.
int	stopTrackPositions () noexcept
	Stops the sense data source improved position tracking on map.
bool	hasDataTransactionInProgress () const noexcept
	Check if the view has data transaction with cloud service in progress.

Detailed Description

MapCustomization object.

Implements share-read / write Api object over IMapViewExtensions.

Member Function Documentation

◆ createTexture()

int gem::MapViewExtensions::createTexture ( IBitmap & bmp ) const

inlinenoexcept

Create texture from the given bitmap.

Parameters

[in] bmp Bitmap data

Returns: On success, returns the texture id which can be used for rendering and deletion

◆ deleteTexture()

int gem::MapViewExtensions::deleteTexture ( int textureId ) const

inlinenoexcept

Delete a texture previously created with createTexture.

Parameters

[in] textureId The id of the texture

Returns: On success, returns 0. On error, returns the error code

◆ getHighlightGroupItemIndex()

int gem::MapViewExtensions::getHighlightGroupItemIndex	(	int	idx,
		int	highlightId = 0 ) const

inlinenoexcept

Get group highlighted item index for the given highlighted item index ( in original list ).

Parameters

[in]	idx	The highlighted item index in original list for which the group head is searched
[in]	highlightId	The highlight collection id ( optional )

Returns: On success, returns the group index in highlighted items original list; On error, returns the error code

◆ getLowEndCPUOptimizations()

bool gem::MapViewExtensions::getLowEndCPUOptimizations ( ) const

inlinenoexcept

Get low end CPU optimizations flag.

Returns: low end CPU optimizations flag

◆ getMarkersFromRouteGeometry()

int gem::MapViewExtensions::getMarkersFromRouteGeometry	(	std::function< void(MarkerCollection, ERouteGeometryMarkerType)>	collector,
		const DataBuffer &	data ) const

inlinenoexcept

Generate markers collection from route packed geometry.

Parameters

[in]	collector	Marker collector
[in]	data	Route packed geometry

Returns: Error code

◆ getMarkersFromRouteInstructionGeometry()

std::pair< MarkerCollection, AbstractGeometryImage > gem::MapViewExtensions::getMarkersFromRouteInstructionGeometry ( const DataBuffer & data ) const

inlinenoexcept

Generate marker collection from route instruction packed geometry.

Parameters

[in] data Route instruction packed geometry

Returns: pair MarkerCollection and AbstractGeometryImage

◆ getMarkersFromRouteTrafficGeometry()

std::pair< RouteTrafficEventList, int > gem::MapViewExtensions::getMarkersFromRouteTrafficGeometry	(	std::function< void(MarkerCollection, ETrafficEventSeverity)>	collector,
		const DataBuffer &	data ) const

inlinenoexcept

Generate markers collection from route traffic packed geometry.

Parameters

[in]	collector	Marker collector
[in]	data	Route packed geometry

Returns: Error code

◆ getMaximumAllowedZoomLevel()

int gem::MapViewExtensions::getMaximumAllowedZoomLevel ( ) const

inlinenoexcept

Get the maximum allowed zoom level.

Returns: The maximum allowed zoom level

◆ getMinimumAllowedZoomLevel()

int gem::MapViewExtensions::getMinimumAllowedZoomLevel ( ) const

inlinenoexcept

Get the minimum allowed zoom level.

Returns: The minimum allowed zoom level

◆ getNavigationRouteLowRateUpdate()

bool gem::MapViewExtensions::getNavigationRouteLowRateUpdate ( ) const

inlinenoexcept

get navigation route low rate update

Deprecated: Use instead getNavigationRouteLowRateUpdate for multiple options

Returns: navigation route low rate update flag

◆ getNavigationRouteUpdateRate()

ENavigationRouteUpdateRate gem::MapViewExtensions::getNavigationRouteUpdateRate ( ) const

inlinenoexcept

get navigation route update rate

Returns: navigation route update rate

◆ getTrackedPositions()

std::pair< CoordinatesList, int > gem::MapViewExtensions::getTrackedPositions ( ) const

inlinenoexcept

Get the current tracked positions as a coordinates list.

Returns: std::pair<coords list, error>. If tracking is not started the function will return <CoordinatesList(), error::KNotFound>

◆ hasDataTransactionInProgress()

bool gem::MapViewExtensions::hasDataTransactionInProgress ( ) const

inlinenoexcept

Check if the view has data transaction with cloud service in progress.

Returns: true if data transaction is in progress, false otherwise

◆ isTrackedPositions()

bool gem::MapViewExtensions::isTrackedPositions ( ) const

inlinenoexcept

Check if tracked position is started in the map view.

Returns: true if tracked position is started, false otherwise

◆ renderTexture()

int gem::MapViewExtensions::renderTexture	(	int	textureId,
		const Rect &	place ) const

inlinenoexcept

Render bitmap in the map view.

Parameters

[in]	textureId	The texture id created with createTexture
[in]	place	Where to render

Returns: On success, returns 0. On error, returns the error code

◆ setLowEndCPUOptimizations()

MapViewExtensions & gem::MapViewExtensions::setLowEndCPUOptimizations ( bool enable )

inlinenoexcept

Enable optimizations for low end CPU.

Parameters

enable enable optimizations for low end CPU

Returns: MapViewExtensions reference

◆ setMaximumAllowedZoomLevel()

MapViewExtensions & gem::MapViewExtensions::setMaximumAllowedZoomLevel ( int zoomLevel )

inlinenoexcept

Set the maximum allowed zoom level.

Parameters

[in] zoomLevel The maximum allowed zoom level

Returns: MapViewExtensions reference

◆ setMinimumAllowedZoomLevel()

void gem::MapViewExtensions::setMinimumAllowedZoomLevel ( int zoomLevel )

inlinenoexcept

Set the minimum allowed zoom level.

Parameters

[in] zoomLevel The minimum allowed zoom level

◆ setNavigationRouteLowRateUpdate()

MapViewExtensions & gem::MapViewExtensions::setNavigationRouteLowRateUpdate ( bool enable )

inlinenoexcept

set navigation route low rate update

Deprecated: Use instead getNavigationRouteLowRateUpdate for multiple options

Parameters

enable navigation route low rate update flag

Returns: MapViewExtensions reference

◆ setNavigationRouteUpdateRate()

MapViewExtensions & gem::MapViewExtensions::setNavigationRouteUpdateRate ( ENavigationRouteUpdateRate rate )

inlinenoexcept

set navigation route update rate

Parameters

rate	The update rate to be set

Returns: MapViewExtensions reference

◆ startTrackPositions()

int gem::MapViewExtensions::startTrackPositions	(	int	updatePositionMs,
		const MarkerCollectionRenderSettings &	settings,
		sense::DataSourcePtr	ds = {} )

inlinenoexcept

Start the sense data source improved position tracking on map by rendering a marker polyline between relevant map links points.

Parameters

[in]	updatePositionMs	The tracked position collection update frequency. High frequency may decrease rendering performances on low end devices
[in]	settings	The markers collection rendering settings in the map view
[in]	ds	The sense::DataSourcePtr object which positions are tracked. Default uses the PositionService current data source as input

Returns: On success, returns 0. On error, returns the error code.

◆ stopTrackPositions()

int gem::MapViewExtensions::stopTrackPositions ( )

inlinenoexcept

Stops the sense data source improved position tracking on map.

Returns: error::KNotFound if tracking is not started
