Routes

_{Last updated: June 10, 2026 | 12 minutes read}

A route represents a navigable path between two or more landmarks (waypoints), including distance, estimated time, and navigation instructions.

Compute routes in different ways:

Waypoint-based - Based on 2 or more landmarks (navigable)
Over-track - Based on a predefined path from GPX files or other sources (navigable)
Route ranges - Not navigable, without segments or instructions

Navigable routes consist of segments. Each segment represents the portion between consecutive waypoints with its own route instructions.

Create Routes

Routes cannot be instantiated directly. Compute them based on a list of landmarks. See Get started with Routing for details.

danger

Calculating a route does not automatically display it on the map. See Display routes for instructions.

Route types

The iOS SDK supports standard, public transport, over-track, and EV route variants.

Route type	Type checks and conversion	Class
Normal route	default `RouteObject`	`RouteObject`
Public transport	`isPTRoute()` and `toPTRoute()`	`PTRouteObject`
Over-track	`isOTRoute()` and `toOTRoute()`	`OTRouteObject`
Electric vehicle	`isEVRoute()` and `toEVRoute()`	`EVRouteObject`

func inspectType(route: RouteObject) {
	if route.isPTRoute(), let ptRoute = route.toPTRoute() as? PTRouteObject {
		print("PT fare: \(ptRoute.getPTFare())")
	} else if route.isOTRoute(), let otRoute = route.toOTRoute() as? OTRouteObject {
		print("OT route has track: \(otRoute.getTrack() != nil)")
	} else if route.isEVRoute(), route.toEVRoute() is EVRouteObject {
		print("EV route detected")
	} else {
		print("Standard route")
	}
}

RouteObject structure

RouteObject is the shared contract for all route types.

Core methods

Method	Return type	Description
`getWaypoints()`	`[LandmarkObject]`	Route waypoints in order: departure, intermediates, destination
`getWaypoints(_:)`	`[LandmarkObject]`	Waypoints filtered by `RouteWaypointsOption`
`getTimeDistance()`	`TimeDistanceObject?`	Total route metrics
`getTimeDistance(withActivePart:)`	`TimeDistanceObject?`	Metrics for active/remaining part or full route
`getGeographicArea()`	`RectangleGeographicAreaObject?`	Bounding rectangle for the route
`getSummary()`	`String`	Human-readable summary
`getSegments()`	`[RouteSegmentObject]`	Segment list
`getTrafficEvents()`	`[RouteTrafficEventObject]`	Traffic events affecting the route
`getStatus()`	`RouteStatus`	Route lifecycle state
`getIncursCosts()`	`Bool`	Cost-incurring flag
`hasFerryConnections()`	`Bool`	Whether ferry segments are present
`hasTollRoads()`	`Bool`	Whether toll roads are present

func summarize(route: RouteObject) {
	print("Summary: \(route.getSummary())")
	print("Waypoint count: \(route.getWaypoints().count)")

	if let td = route.getTimeDistance() {
		print("Distance (m): \(td.getTotalDistance())")
		print("Duration (s): \(td.getTotalTime())")
	}

	print("Has toll roads: \(route.hasTollRoads())")
	print("Has ferry connections: \(route.hasFerryConnections())")
}

Geometry, sampling, and export

Method	Return type	Description
`getPath()`	`PathObject?`	Full route geometry
`getPath(_:end:)`	`PathObject?`	Geometry subset between two distances
`getCoordinateOnRoute(_:)`	`CoordinatesObject?`	Coordinate sampled at distance from start
`getClosestSegment(_:)`	`Int32`	Closest segment index to a coordinate
`getDistanceOnRoute(_:activePart:)`	`Int32`	Distance from departure to location
`getTimeDistanceCoordinateOnRoute(_:)`	`TimeDistanceCoordinatesObject?`	Distance/time-aligned coordinate on route
`getTimeDistanceCoordinates(from:end:step:stepType:)`	`[TimeDistanceCoordinatesObject]`	Distance or time-stepped route sampling
`export(as:)`	`Data?`	Exports route geometry in a path file format
`export(as:withCompresion:)`	`Data?`	Export with compression flag
`getDominantRoads()`	`[String]`	Main roads covering the route

Preferences and metadata

Method	Return type	Description
`getTerrainProfile()`	`RouteTerrainProfileObject?`	Elevation/slope analytics if enabled in preferences
`getPreferences()`	`RoutePreferencesObject?`	Route preferences used for computation
`getExtraInfo()`	`SearchableParameterListObject?`	User metadata bag
`setExtraInfo(_:)`	`Void`	Sets custom metadata
`isEqualWithRoute(_:)`	`Bool`	Equality check against another route

RouteWaypointsOption

Value	Description
`RouteWaypointsOptionInitial`	Initial waypoints used at first route calculation
`RouteWaypointsOptionRemainingInitial`	Remaining initial waypoints (passed intermediates removed)
`RouteWaypointsOptionRemaining`	Remaining waypoints including service-added entries

RouteStatus

Value	Description
`RouteStatusUninitialized`	Route object has no ready data
`RouteStatusCalculating`	Calculation in progress
`RouteStatusWaitingInternetConnection`	Waiting for connectivity
`RouteStatusReady`	Route data is ready
`RouteStatusError`	Calculation failed

Sample route geometry and export

if let path = route.getPath() {
    print("Route points: \(path.getCoordinates().count)")
}
if let gpxData = route.export(as: .gpx) {
    print("Exported GPX size: \(gpxData.count) bytes")
}
if let point = route.getCoordinateOnRoute(2_000) {
    print("Coordinate at 2km: \(point.latitude), \(point.longitude)")
}
let samples = route.getTimeDistanceCoordinates(from: 0, end: 5_000, step: 500, stepType: true)
for sample in samples {
    print("distance=\(sample.getDistance()) ts=\(sample.getTimestamp())")
}

RouteSegmentObject structure

A RouteSegmentObject represents the route portion between two consecutive waypoints.

Method	Return type	Description
`getWaypoints()`	`[LandmarkObject]`	Segment departure and destination waypoints
`getTimeDistance()`	`TimeDistanceObject?`	Segment distance and travel time
`getGeographicArea()`	`RectangleGeographicAreaObject?`	Segment bounding rectangle
`getIncursCosts()`	`Bool`	Segment cost-incurring flag
`getSummary()`	`String`	Segment summary text
`getInstructions()`	`[RouteInstructionObject]`	Segment turn instructions
`getPTInstructions()`	`[PTRouteInstructionObject]`	PT instruction list
`isCommon()`	`Bool`	Segment mode matches parent route mode

for (index, segment) in route.getSegments().enumerated() {
	print("Segment \(index): \(segment.getSummary())")

	if let td = segment.getTimeDistance() {
		print("  \(td.getTotalDistance()) m / \(td.getTotalTime()) s")
	}

	for instruction in segment.getInstructions() {
		print("  - \(instruction.getTurnInstruction())")
	}
}

RouteInstructionObject structure

RouteInstructionObject provides maneuver details, signposts, and road metadata.

Method	Return type	Description
`getCoordinates()`	`CoordinatesObject`	Instruction location
`getCountryCodeISO()`	`String`	ISO country code
`getTurnInstruction()`	`String`	Maneuver text
`getTurnDetails()`	`TurnDetailsObject?`	Turn detail metadata
`getTurnImage(_:)`	`UIImage?`	Turn image at requested size
`hasTurnInfo()`	`Bool`	Turn info availability
`getFollowRoadInstruction()`	`String`	Follow-road text
`hasFollowRoadInfo()`	`Bool`	Follow-road availability
`getSignpostInstruction()`	`String`	Signpost text
`getSignpostDetails()`	`SignpostDetailsObject?`	Signpost detail object
`hasSignpostInfo()`	`Bool`	Signpost availability
`getRoadInfo()`	`[RoadInfoObject]`	Road metadata list
`getRoadInfoImage(_:)`	`UIImage?`	Road info rendered image
`hasRoadInfo()`	`Bool`	Road info availability
`getTimeDistanceToNextTurn()`	`TimeDistanceObject?`	Remaining metrics to next maneuver
`getRemainingTravelTimeDistance()`	`TimeDistanceObject?`	Remaining metrics to destination
`getRemainingTravelTimeDistanceToNextWaypoint()`	`TimeDistanceObject?`	Remaining metrics to next waypoint
`getTraveledTimeDistance()`	`TimeDistanceObject?`	Traveled metrics
`getExitDetails()`	`String`	Exit details text
`isExit()`	`Bool`	Main-road exit flag
`isFerry()`	`Bool`	Ferry instruction flag
`isTollRoad()`	`Bool`	Toll-road instruction flag
`isCommon()`	`Bool`	Shares parent route transport mode
`isEV()`	`Bool`	Instruction belongs to EV route

info

RouteInstructionObject is route-overview data. For live, position-dependent turn guidance during navigation, use NavigationInstructionObject.

if let instruction = route.getSegments().first?.getInstructions().first {
	print(instruction.getTurnInstruction())

	let turnImage = instruction.getTurnImage(CGSize(width: 64, height: 64))
	print("Turn image available: \(turnImage != nil)")

	if instruction.hasRoadInfo() {
		print("Road info count: \(instruction.getRoadInfo().count)")
	}
}

Public transport route extensions

PTRouteObject

PTRouteObject adds transit-specific details on top of RouteObject.

Method	Return type	Description
`getPTFare()`	`String`	Fare text
`getPTFrequency()`	`Int`	Frequency value
`getPTRespectsAllConditions()`	`Bool`	Whether all PT preferences are met
`getCountBuyTicketInformation()`	`Int`	Ticket info entry count
`getBuyTicketURL(_:)`	`String`	Ticket purchase URL for entry index
`getSolutionPartIndexes(_:)`	`[NSNumber]`	Route-solution part indexes for ticket info

if route.isPTRoute(), let ptRoute = route.toPTRoute() as? PTRouteObject {
	print("Fare: \(ptRoute.getPTFare())")
	print("Frequency: \(ptRoute.getPTFrequency())")

	let ticketInfoCount = ptRoute.getCountBuyTicketInformation()
	for i in 0..<ticketInfoCount {
		let index = Int32(i)
		print("Ticket URL: \(ptRoute.getBuyTicketURL(index))")
		print("Affected parts: \(ptRoute.getSolutionPartIndexes(index))")
	}
}

PTRouteSegmentObject

PTRouteSegmentObject provides schedule, agency, line, and realtime details.

Method	Return type	Description
`getName()`	`String`	Segment/display name
`getShortName()`	`String`	Segment short name
`getPlatformCode()`	`String`	Platform code
`getDepartureTime()` / `getArrivalTime()`	`TimeObject?`	Raw departure/arrival times
`getDepartureTimeFormatted()` / `getArrivalTimeFormatted()`	`String`	Formatted time strings
`getAgencyName()`	`String`	Agency name
`getAgencyPhone()` / `getAgencyUrl()` / `getAgencyFareUrl()`	`String`	Agency contact and fare URLs
`getLineFrom()` / `getLineTowards()`	`String`	Transit line origin/destination
`getTransitType()`	`TransitType`	Transport mode (`walk`, `bus`, `tram`, etc.)
`getRealtimeStatus()`	`RealtimeStatus`	Delay/on-time/unknown status
`getDepartureDelayInSeconds()` / `getArrivalDelayInSeconds()`	`Int32`	Delay values in seconds
`getHasWheelchairSupport()` / `getHasBicycleSupport()`	`Bool`	Accessibility/bike support flags
`getStayOnSameTransit()`	`Bool`	Stay-on-vehicle indicator
`getLineColor()` / `getLineTextColor()`	`UIColor`	Line rendering colors
`getCountAlerts()`	`Int32`	Alert count for segment
`isSignificant()`	`Bool`	Indicates if segment is worth surfacing in UI

PTRouteInstructionObject

Method	Return type	Description
`getName()`	`String`	PT instruction label
`getPlatformCode()`	`String`	Platform code
`getArrivalTime()` / `getDepartureTime()`	`TimeObject?`	PT arrival/departure data
`getHasWheelchairSupport()`	`Bool`	Accessibility support flag

Route traffic updates via delegate

Assign RouteObjectDelegate when you need route-level traffic update callbacks.

Delegate callback	Description
`routeObject(_:onTrafficEventsUpdated:)`	Called when route traffic events change; includes delay difference
`routeObject(_:onTrafficEventsAlongRoute:)`	Called when traffic-event verification status changes

final class RouteObserver: NSObject, RouteObjectDelegate {
	func routeObject(_ route: RouteObject, onTrafficEventsUpdated delayDiff: Int32) {
		print("Route delay delta: \(delayDiff) s")
	}

	func routeObject(_ route: RouteObject, onTrafficEventsAlongRoute checked: Bool) {
		print("Traffic events verified: \(checked)")
	}
}

TimeDistanceObject

TimeDistanceObject is used across route, segment, and instruction APIs.

Method	Return type	Description
`getTotalTime()` / `getTotalDistance()`	`UInt32`	Total duration/distance
`getUnrestrictedTime()` / `getUnrestrictedDistance()`	`UInt32`	Public-road travel metrics
`getRestrictedTime()` / `getRestrictedDistance()`	`UInt32`	Restricted-road metrics
`getRestrictedTimeAtBegin()` / `getRestrictedTimeAtEnd()`	`UInt32`	Restricted-time split over begin/end
`getRestrictedDistanceAtBegin()` / `getRestrictedDistanceAtEnd()`	`UInt32`	Restricted-distance split over begin/end
`getTotalDistanceMeasurement()`	`Measurement<UnitLength>`	Measurement object with unit support
`getTotalDistanceFormatted()` / `getTotalDistanceUnitFormatted()`	`String`	Localized distance value/unit
`getTotalTimeFormatted()` / `getTotalTimeUnitFormatted()`	`String`	Localized time value/unit
`getFormattedDistance(_:)` / `getFormattedDistanceUnit(_:)`	`String`	Formatted value/unit for arbitrary meters

TurnDetailsObject

Method	Return type	Description
`getEvent()`	`TurnType`	Turn event enum
`getAbstractGeometry()`	`AbstractGeometryObject?`	Vector geometry for turn
`getAbstractGeometryImage()`	`AbstractGeometryImageObject?`	Renderable abstract geometry image
`getRoundaboutExitNumber()`	`Int32`	Exit number or `-1` if unavailable
`getTurnImage(_:colorActiveInner:colorActiveOuter:colorInactiveInner:colorInactiveOuter:)`	`UIImage?`	Color-customized turn image
`getTurnImageId()`	`Int32`	Turn image ID
`getTurnId32()` / `getTurnId64()`	`TurnSimplifiedType32` / `TurnSimplifiedType64`	Simplified maneuver IDs

let scale = UIScreen.main.scale
let imgSize = CGSize.init(width: 40.0 * scale, height: 40.0 * scale)

turnDetailsObject.getTurnImage(imgSize,
		colorActiveInner: UIColor.white,
		colorActiveOuter: UIColor.black,
		colorInactiveInner: UIColor.lightGray,
		colorInactiveOuter: UIColor.lightGray)

turnDetailsObject.getTurnImage(imgSize,
		colorActiveInner: UIColor.red,
		colorActiveOuter: UIColor.green,
		colorInactiveInner: UIColor.blue,
		colorInactiveOuter: UIColor.yellow)

Turn Image with basic colors

Turn Image with customized colors

SignpostDetailsObject

Signposts near roadways indicate intersections and directions. The SDK provides realistic image renderings with additional information.

Signpost image captured during highway navigation

Method	Return type	Description
`getItems()`	`[SignpostItemObject]`	Signpost elements
`hasBorderColor()` / `getBorderColor()`	`Bool` / `UIColor`	Border color availability/value
`hasTextColor()` / `getTextColor()`	`Bool` / `UIColor`	Text color availability/value
`hasBackgroundColor()` / `getBackgroundColor()`	`Bool` / `UIColor`	Background color availability/value
`getImage(_:)`	`UIImage?`	Rendered signpost image

RouteTerrainProfileObject

If route preferences enabled terrain profile generation, getTerrainProfile() returns this object.

Method	Return type	Description
`getMinElevation()` / `getMaxElevation()`	`Float`	Min/max elevation
`getMinElevationDistance()` / `getMaxElevationDistance()`	`Int32`	Distances for min/max elevation points
`getTotalUp()` / `getTotalDown()`	`Float`	Total ascent/descent
`getTotalUp(_:end:)` / `getTotalDown(_:end:)`	`Float`	Ascent/descent for route range
`getElevationSamples(_:)`	`[NSNumber]`	Elevation sample list
`getElevationSamples(_:distBegin:distEnd:)`	`[NSNumber]`	Elevation samples for route subsection
`getElevation(_:)`	`Float`	Elevation at distance
`getClimbSections()`	`[ClimbSectionObject]`	Climb sections
`getSurfaceSections()`	`[SurfaceSectionObject]`	Surface type sections
`getRoadTypeSections()`	`[RoadTypeSectionObject]`	Road type sections
`getSteepSections(_:)`	`[RoadSteepSectionObject]`	Steepness-classified sections
`getElevationChartMinValueY()` / `getElevationChartMaxValueY()`	`Float`	Chart range helpers

RouteTrafficEventObject

RouteTrafficEventObject extends traffic-event data with route-relative context.

Method	Return type	Description
`getDistanceToDestination()`	`Int32`	Distance from event to destination
`getFrom()` / `getTo()`	`CoordinatesObject?`	Event start/end coordinates
`getFromLandmark()` / `getToLandmark()`	`LandmarkObject?`	Event start/end landmarks
`hasTrafficEventOnDistance(_:)`	`Bool`	Whether event affects the remaining route distance
`isInsideTrafficEventOnDistance(_:)`	`Bool`	Whether the point is inside event impact zone
`getDistanceFormatted()` / `getDistanceUnitFormatted()`	`String`	Formatted event distance
`getDelayTimeFormatted()` / `getDelayTimeUnitFormatted()`	`String`	Formatted delay time
`getDelayDistanceFormatted()` / `getDelayDistanceUnitFormatted()`	`String`	Formatted delay distance

Use RouteObject as the base route contract, then branch to PTRouteObject, OTRouteObject, or EVRouteObject only when route-type-specific behavior is needed.

Create Routes​

Route types​

RouteObject structure​

Core methods​

Geometry, sampling, and export​

Preferences and metadata​

RouteWaypointsOption​

RouteStatus​

Sample route geometry and export​

RouteSegmentObject structure​

RouteInstructionObject structure​

Public transport route extensions​

PTRouteObject​

PTRouteSegmentObject​

PTRouteInstructionObject​

Route traffic updates via delegate​

Related classes​

TimeDistanceObject​

TurnDetailsObject​

SignpostDetailsObject​

RouteTerrainProfileObject​

RouteTrafficEventObject​
