Offline Routing
In this guide, you will learn how to implement offline routing functionality using the Maps SDK for Flutter. This example demonstrates how to download a map for offline use, disable internet access, and calculate routes offline.
How it works
This example demonstrates the following features:
- Download specific maps (e.g., for “Andorra”) to enable offline functionality.
- Disable internet access after successful map download to enforce offline usage.
- Compute routes offline between predefined waypoints, using the downloaded map data.
UI and Map Integration
main.dartView on Github
void main() {
runApp(const MyApp());
}
class MyApp extends StatelessWidget {
const MyApp({super.key});
Widget build(BuildContext context) {
return const MaterialApp(
debugShowCheckedModeBanner: false,
title: 'Offline Routing',
home: MyHomePage(),
);
}
}
class MyHomePage extends StatefulWidget {
const MyHomePage({super.key});
State<MyHomePage> createState() => _MyHomePageState();
}
class _MyHomePageState extends State<MyHomePage> {
late GemMapController _mapController;
bool _areRoutesBuilt = false;
// We use the handler to cancel the route calculation.
TaskHandler? _routingHandler;
bool _isDownloaded = false;
double _downloadProgress = 0;
void dispose() {
GemKit.release();
super.dispose();
}
Widget build(BuildContext context) {
return Scaffold(
appBar: AppBar(
backgroundColor: Colors.deepPurple[900],
title: const Text(
'Offline Routing',
style: TextStyle(color: Colors.white),
),
actions: [
// Map is downloading.
if (_isDownloaded == false && _downloadProgress != 0)
Container(
width: 20,
height: 20,
margin: const EdgeInsets.only(right: 10.0),
child: const Center(
child: CircularProgressIndicator(color: Colors.white),
),
),
// Map is not downloaded.
if (_isDownloaded == false && _downloadProgress == 0)
IconButton(
onPressed: () => _setOfflineMap(),
icon: const Icon(Icons.download, color: Colors.white),
),
// Routes are not built.
if (_routingHandler == null &&
_areRoutesBuilt == false &&
_isDownloaded == true)
IconButton(
onPressed: () => _onBuildRouteButtonPressed(context),
icon: const Icon(Icons.route, color: Colors.white),
),
// Routes calculating is in progress.
if (_routingHandler != null)
IconButton(
onPressed: () => _onCancelRouteButtonPressed(),
icon: const Icon(Icons.stop, color: Colors.white),
),
// Routes calculating is finished.
if (_areRoutesBuilt == true)
IconButton(
onPressed: () => _onClearRoutesButtonPressed(),
icon: const Icon(Icons.clear, color: Colors.white),
),
],
),
body: GemMap(
key: ValueKey("GemMap"),
onMapCreated: _onMapCreated,
appAuthorization: projectApiToken,
),
);
}
void _onMapCreated(GemMapController controller) async {
// Save controller for further usage.
_mapController = controller;
SdkSettings.setAllowOffboardServiceOnExtraChargedNetwork(
ServiceGroupType.contentService,
true,
);
}
Define Route Calculation Logic
Implement methods to build routes based on predefined waypoints and manage the download of maps.
main.dartView on Github
void _onBuildRouteButtonPressed(BuildContext context) {
// Define the departure.
final departureLandmark = Landmark.withLatLng(
latitude: 42.49720,
longitude: 1.50498,
);
// Define the destination.
final destinationLandmark = Landmark.withLatLng(
latitude: 42.51003,
longitude: 1.53400,
);
// Define the route preferences.
final routePreferences = RoutePreferences();
_showSnackBar(context, message: "The route is being calculated.");
// Calling the calculateRoute SDK method.
// (err, results) - is a callback function that gets called when the route computing is finished.
// err is an error enum, results is a list of routes.
_routingHandler = RoutingService.calculateRoute(
[departureLandmark, destinationLandmark],
routePreferences,
(err, routes) {
// If the route calculation is finished, we don't have a progress listener anymore.
_routingHandler = null;
ScaffoldMessenger.of(context).clearSnackBars();
// If there aren't any errors, we display the routes.
if (err == GemError.success) {
// Get the routes collection from map preferences.
final routesMap = _mapController.preferences.routes;
// Display the routes on map.
for (final route in routes) {
routesMap.add(
route,
route == routes.first,
label: getMapLabel(route),
);
}
// Center the camera on routes.
_mapController.centerOnRoutes(routes: routes);
setState(() {
_areRoutesBuilt = true;
});
}
},
);
setState(() {});
}
void _onClearRoutesButtonPressed() {
// Remove the routes from map.
_mapController.preferences.routes.clear();
setState(() {
_areRoutesBuilt = false;
});
}
void _onCancelRouteButtonPressed() {
// If we have a progress listener we cancel the route calculation.
if (_routingHandler != null) {
RoutingService.cancelRoute(_routingHandler!);
setState(() {
_routingHandler = null;
});
}
}
Define Map Downloading Logic
Implement methods for downloading and managing the offline map.
main.dartView on Github
Future<List<ContentStoreItem>> _getMaps() async {
Completer<List<ContentStoreItem>> mapsList =
Completer<List<ContentStoreItem>>();
ContentStore.asyncGetStoreContentList(ContentType.roadMap, (
err,
items,
isCached,
) {
if (err == GemError.success && items.isNotEmpty) {
mapsList.complete(items);
}
});
return mapsList.future;
}
// Check and download Andorra's map if it's not already downloaded on the device.
void _setOfflineMap() {
// Method to load the local maps
final localMaps = ContentStore.getLocalContentList(ContentType.roadMap);
// Check if map is already downloaded
if (localMaps.where((map) => map.name == 'Andorra').isNotEmpty) {
setState(() {
_isDownloaded = true;
});
// Deny internet connection
SdkSettings.setAllowInternetConnection(false);
return;
}
_getMaps().then((maps) {
_downloadProgress = maps[4].downloadProgress.toDouble();
_downloadMap(maps[4]);
});
}
void _downloadMap(ContentStoreItem map) {
// Download the map.
map.asyncDownload(
_onMapDownloadFinished,
onProgress: _onMapDownloadProgressUpdated,
allowChargedNetworks: true,
);
}
void _onMapDownloadProgressUpdated(int progress) {
setState(() => _downloadProgress = progress.toDouble());
}
void _onMapDownloadFinished(GemError err) {
// If there is no error, we change the state
if (err == GemError.success) {
// Deny internet connection
SdkSettings.setAllowInternetConnection(false);
setState(() => _isDownloaded = true);
}
}
Show SnackBar for User Feedback
Implement a method to show a SnackBar for providing feedback to the user.
main.dartView on Github
final snackBar = SnackBar(content: Text(message), duration: duration);
ScaffoldMessenger.of(context).showSnackBar(snackBar);
}
}
Utility methods for Route Labeling
main.dartView on Github
String getMapLabel(Route route) {
return '${convertDistance(route.getTimeDistance().totalDistanceM)} \n${convertDuration(route.getTimeDistance().totalTimeS)}';
}
// Utility function to convert the meters distance into a suitable format.
String convertDistance(int meters) {
if (meters >= 1000) {
double kilometers = meters / 1000;
return '${kilometers.toStringAsFixed(1)} km';
} else {
return '${meters.toString()} m';
}
}
// Utility function to convert the seconds duration into a suitable format.
String convertDuration(int seconds) {
int hours = seconds ~/ 3600; // Number of whole hours
int minutes = (seconds % 3600) ~/ 60; // Number of whole minutes
String hoursText = (hours > 0) ? '$hours h ' : ''; // Hours text
String minutesText = '$minutes min'; // Minutes text
return hoursText + minutesText;
}
