Camera Feed
This example demonstrates how to build a Flutter app using the Maps SDK to display a live camera feed (while recording) and overlay it on the map.
How it works
The example app highlights the following features:
- Initializing the GemKit SDK.
- Requesting and handling camera, microphone, and location permissions.
- Starting and stopping video recording with the device’s camera.
- Streaming the live camera frames to a
GemCameraPlayerwidget. - Overlaying the camera preview on top of the map.
- Properly disposing of resources when recording stops or the app is closed.
UI and Map Integration
The following code builds the UI with a GemMap widget and an app bar that includes buttons for starting/stopping recording and streaming the camera feed.
main.dartView on Github
class MyApp extends StatelessWidget {
const MyApp({super.key});
Widget build(BuildContext context) {
return const MaterialApp(
debugShowCheckedModeBanner: false,
title: 'Camera feed',
home: MyHomePage(),
);
}
}
class MyHomePage extends StatefulWidget {
const MyHomePage({super.key});
State<MyHomePage> createState() => _MyHomePageState();
}
class _MyHomePageState extends State<MyHomePage> {
Recorder? _recorder;
DataSource? _ds;
GemCameraPlayerController? _cameraPlayerController;
void initState() {
super.initState();
}
void dispose() {
GemKit.release();
super.dispose();
}
void _watchPlayerStatus() {
_cameraPlayerController?.addListener(() {
if (_cameraPlayerController!.status == GemCameraPlayerStatus.playing) {
setState(() {}); // Size likely available now
}
});
}
Widget build(BuildContext context) {
return MaterialApp(
home: Scaffold(
appBar: AppBar(
backgroundColor: Colors.deepPurple[900],
title: const Text(
'Camera feed',
style: TextStyle(color: Colors.white),
),
actions: [
IconButton(
icon: Icon(Icons.play_arrow, color: Colors.white),
onPressed: () async {
if (_cameraPlayerController == null) {
_ds = DataSource.createLiveDataSource()!;
_ds!.start();
_recorder = Recorder.create(
RecorderConfiguration(
logsDir: await getDirectoryPath('Tracks'),
dataSource: _ds!,
videoQuality: Resolution.hd720p,
recordedTypes: [DataType.position, DataType.camera],
transportMode: RecordingTransportMode.car,
),
);
await _recorder!.startRecording();
_cameraPlayerController = GemCameraPlayerController(
dataSource: _ds!,
);
_watchPlayerStatus();
setState(() {});
}
},
),
IconButton(
icon: Icon(Icons.stop, color: Colors.white),
onPressed: () async {
await _recorder!.stopRecording();
_cameraPlayerController?.dispose();
_ds?.stop();
_cameraPlayerController = null;
_ds = null;
setState(() {});
},
),
],
),
body: Stack(
children: [
GemMap(
key: ValueKey("GemMap"),
onMapCreated: (controller) => _onMapCreated(controller),
appAuthorization: projectApiToken,
),
Positioned(
top: 10,
left: 10,
child: SafeArea(
top: true,
left: true,
child: Builder(
builder: (context) {
final controller = _cameraPlayerController;
if (controller == null ||
controller.isDisposed ||
controller.status != GemCameraPlayerStatus.playing ||
controller.size == null) {
return const SizedBox(
width: 150,
height: 150,
child: Center(child: CircularProgressIndicator()),
);
}
return SizedBox(
width: 200,
child: AspectRatio(
aspectRatio: controller.size!.$1.toDouble() / controller.size!.$2.toDouble(),
child: GemCameraPlayer(
controller: controller,
fit: BoxFit.cover,
),
),
);
},
),
),
),
],
),
),
);
}
Requesting Location Permission
Before streaming or recording, the app requests camera, microphone, and location permissions:
main.dartView on Github
void _onMapCreated(GemMapController controller) async {
await [
Permission.camera,
Permission.locationWhenInUse,
].request();
}
Starting Recording and Camera Feed
Tapping the Play button initializes the live data source, starts recording, and sets up the GemCameraPlayerController to stream frames:
main.dartView on Github
onPressed: () async {
if (_cameraPlayerController == null) {
_ds = DataSource.createLiveDataSource()!;
_ds!.start();
_recorder = Recorder.create(
RecorderConfiguration(
logsDir: await getDirectoryPath('Tracks'),
dataSource: _ds!,
videoQuality: Resolution.hd720p,
recordedTypes: [DataType.position, DataType.camera],
transportMode: RecordingTransportMode.car,
),
);
await _recorder!.startRecording();
_cameraPlayerController = GemCameraPlayerController(
dataSource: _ds!,
);
_watchPlayerStatus();
setState(() {});
}
},
Stopping Recording and Disposing Resources
Tapping the Stop button stops the recorder, disposes the player, and stops the data source:
main.dartView on Github
onPressed: () async {
await _recorder!.stopRecording();
_cameraPlayerController?.dispose();
_ds?.stop();
_cameraPlayerController = null;
_ds = null;
setState(() {});
},
Stopping Recording and Disposing Resources
A small, resizable preview of the camera feed is overlaid in the top-left corner using GemCameraPlayer:
main.dartView on Github
Positioned(
top: 10,
left: 10,
child: SafeArea(
top: true,
left: true,
child: Builder(
builder: (context) {
final controller = _cameraPlayerController;
if (controller == null ||
controller.isDisposed ||
controller.status != GemCameraPlayerStatus.playing ||
controller.size == null) {
return const SizedBox(
width: 150,
height: 150,
child: Center(child: CircularProgressIndicator()),
);
}
return SizedBox(
width: 200,
child: AspectRatio(
aspectRatio: controller.size!.$1.toDouble() / controller.size!.$2.toDouble(),
child: GemCameraPlayer(
controller: controller,
fit: BoxFit.cover,
),
),
);
},
),
),
),
Utility Functions
The getDirectoryPath function retrieves the root directory path for the app and returns the desired directory path inside the "Data" folder.
utils.dartView on Github
import 'package:path_provider/path_provider.dart' as path_provider;
import 'package:path/path.dart' as path;
import 'dart:io';
Future<String> getDirectoryPath(String dirName) async {
final docDirectory = Platform.isAndroid
? await path_provider.getExternalStorageDirectory()
: await path_provider.getApplicationDocumentsDirectory();
String absPath = docDirectory!.path;
final expectedPath = path.joinAll([absPath, "Data", dirName]);
return expectedPath;
}
Required Permissions
To ensure this example functions correctly, the necessary permissions must be added to the project's Android and iOS configuration files:
- Android
- iOS
Add the following code to the android/app/src/main/AndroidManifest.xml file, within the <manifest> block:
<uses-permission android:name="android.permission.ACCESS_FINE_LOCATION" />
<uses-permission android:name="android.permission.ACCESS_COARSE_LOCATION" />
<uses-permission android:name="android.permission.CAMERA" />
<uses-permission android:name="android.permission.RECORD_AUDIO" />This example uses the Permission Handler package. Be sure to follow the setup guide.
Add the following to ios/Runner/Info.plist inside the <dict>:
<key>NSLocationWhenInUseUsageDescription</key>
<string>Location is needed for map localization and navigation</string>
<key>NSCameraUsageDescription</key>
<string>Camera access is needed for video recording</string>
<key>NSMicrophoneUsageDescription</key>
<string>We need microphone access to record audio.</string>This example uses the Permission Handler package. Follow the official setup instructions. Add this to your ios/Podfile:
post_install do |installer|
installer.pods_project.targets.each do |target|
flutter_additional_ios_build_settings(target)
target.build_configurations.each do |config|
config.build_settings['GCC_PREPROCESSOR_DEFINITIONS'] ||= [
'$(inherited)',
'PERMISSION_LOCATION=1',
'PERMISSION_CAMERA=1',
'PERMISSION_MICROPHONE=1'
]
end
end
end
